Pricing from $16,490 inc GST fitted

The Tray Norweld is known for! Our Deluxe Tray is the envy of the industry. Fully welded construction, heavy duty floor plate and beautiful design make it hard to go past the Deluxe Tray.

By far our most popular model, built to take whatever you can throw at it, whilst offering the maximum vehicle payload by saving up to 200kg compared to similar steel trays.

The Plus version adds colour coded sideboards and toolbox lids, with stainless steel capping.

Get a quote

Deluxe Plus Trays Package Inclusions

1 Piece Floor

76mm Tube Headboard

1200mm Long Drawer

Extruded Sideboards

LED Tail Lights

Poly Water Tank

Package Includes:

  • Transferable between vehicle models (excluding Land Cruiser and American Utes)
  • Painted sideboards/tailgate and toolbox lids with stainless steel capping
  • 4mm high tensile single piece plate floor
  • 5mm checker plate side rails
  • Extruded sideboards with built in stiffeners
  • 76mm x 38mm x 6mm high tensile aluminium chassis runners
  • 76mm x 5mm mandrel bend tube headboard
  • Spare wheel holders integrated into the headboard
  • Heavy duty stainless hinges and catches
  • Maxi Lamp LED tail lights
  • Router cut 10mm plate mounts
  • One piece flared guards or Mudguards bolt on with adjustable mounting
  • Front and Rear Under Tray Toolboxes Included
  • 1200mm x 150mm rear drawer integrated into tray
  • 58 litre poly water tank
  • Norweld’s own Dual Locking Roller Compression Locks
  • WEIGHT from 233 kgs

Please Note:

  • Radar relocation kits are available for 2021 Dmax and BT50.
  • Sensor relocation kits are available for Ford Ranger, Toyota Hilux, Holden Colorado and LC200.
  • Genuine Camera relocation kits included for Hilux, Ranger, BT50, Colorado, Dmax and Navara
  • Lengths available 1826mm for Dual Cab and 2126mm for Space Cab Hilux, Ranger, Dmax, BT50, Colorado and Navara
  • LC79 Lengths available 1826mm for Dual Cab and 2526mm for Single Cab. 300mm Extended LC79 Length is 1986mm
  • LC200 Lengths available 1986mm for 650/750mm extension and 2286mm for 950mm extension.

Get a quote

Single Cab Toyota Landcruiser with Deluxe Plus Tray and Additional Back Rack Accessory

Dual Cab Toyota Landcruiser with Deluxe Plus Tray Additional Back Rack Accessory

Included 1200mm Under Tray Drawer

Included Water Tank plumbed to headboard

Dual Cab Toyota Landcruiser with Deluxe Plus Tray

Included Water Tap with swivel fitting

Included Under Tray Toolboxes

Included Dual Spare Wheel mounts

Dual Cab Toyota Hilux with Deluxe Plus Tray

Dual Cab Toyota Landcruiser with twin 35″ wheels

Dual Cab Toyota Landcruiser with Deluxe Plus Tray
